UIP | USB 2.0 Galvanic isolator for Audio
$495.00
Shipping calculated at checkout.
Description
UIP isolates the USB connection between your source and DAC, with regenerated power and an OCXO-based clock system.
TYPICAL AUDIO CONNECTION
HOST SIDE
USB-B
1 × IN
→
INSIDE UIP
Galvanic
isolation
isolation
→
DAC SIDE
USB-A
1 × OUT
Connect your computer or USB source through UIP to your USB DAC. ADuM4165 isolates USB data; the output receives regenerated power.
USB 2.0 HIGH SPEED
480Mbps
Supports up to
PCM 768 kHz
DSD512*
LINEAR POWER
4 power rails.
Independent low-noise regulation for the OCXO, USB output and both sides of the isolator.
2 × LT3042 + PNP
2 × LT3042
Talema transformer.
PRECISION CLOCK
OCXO + PLL
Built-in SC-cut OCXO and PLL provide a precision clock reference for USB reclocking.
Optional external master clock → 1 × BNC IN · 10 MHz
*Requires a compatible USB source, playback software and DAC. USB-B / USB-A labels identify the ports on UIP.
